B7218-E-T-P4S-DBL Machine tool main spindle bearing 90x160x30 mm,Back to back arrangement,duplex set

Place of Origin : Germany

Brand Name : FAG

Model Number : B7218-E-T-P4S-DBL

Certification : ORIGINAL

Price : NEGOTIATION

Packaging Details : Standard carton

Delivery Time : 2 days

Payment Terms : T/T

Supply Ability : 1000PCS/MONTH

MOQ : 2PCS

Contact Now

FAG bearings B7218.E.T.P4S.DBL

adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances

d: 90mm D: 160mm B: 30mm

Type:

B

Standard Steel balls

Dimension series:

72

Heavy series

Dimension（dxDxh）

90x160x30mm

Contact angle:

C

C =15° E = 25°

Cages:

T

Plastic fiber cage, outer ring guided

Precision:

P4S

P4S FAG standard, reference to DIN620, higher than P4

Bearing arrangement:

DB

Duplex set back to back arrangement

Preload:

L

light preload

B7218.E.T.P4S.DBL High Precision Ball Bearing，Machine tool main spindle bearing
B7218.E.T.P4S.DBL FAG High Speed Angular Spindle Ball Bearing
25 degrees Contact Angle
P4 Grade
90mm x 160mm x 30mm
Made in Germany

B7218-E-T-P4S-DBL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 25 degrees contact angle and Phenolic cage, bearing is P4 quality and made in Germany

Item: B7218ETP4SDUL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel

Quality: P4 Grade

Dimensions: 90mm x 160mm x 30mm /Metric

ID (inner diameter)/Bore: 90mm

OD (outer diameter): 160mm

Width/Height/thickness: 30mm

Size:90 x 160 x 30 mm

Quantity: One Bearing

Dynamic load rating Cr: 122000 N

Static load rating Cor: 104000 N

Limiting Speed:

Grease Lubrication: 8500 RPM

Oil Lubrication: 14,000 RPM

Made in Germany

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

B7218-E-T-P4S-DBL Machine tool main spindle bearing 90x160x30 mm,Back to back arrangement,duplex set
