B7022.E.T.P4S.UL FAG original machine tool main spindle bearing,110x170x28mm,B7022.E.T.P4S.UL Spindle bearing

Place of Origin : Germany

Brand Name : FAG

Model Number : B7022-E-T-P4S-UL

Certification : ORIGINAL

Price : NEGOTIATION

Packaging Details : Standard carton

Delivery Time : 2 days

Payment Terms : T/T

Supply Ability : 1000PCS/MONTH

MOQ : 2PCS

Contact Now

FAG bearings B7022-E-T-P4S-UL

adjusted, in pairs or sets, contact angle α = 25°, restricted tolerances

d: 110mm D: 170mm B: 28mm

Type:

B

Standard Steel balls

Dimension series:

70

Medium series

Dimension（dxDxh）

110x170x28mm

Contact angle:

C

C =15° E = 25°

Cages:

T

Plastic fiber cage, outer ring guided

Precision:

P4S

P4S FAG standard, reference to DIN620, higher than P4

Bearing arrangement:

U

single bearing, universal assemble

Preload:

L

light preload

B7022.E.T.P4S.UL High Precision Ball Bearing，Machine tool main spindle bearing
B7022.E.T.P4S.UL FAG High Speed Angular Spindle Ball Bearing
25 degrees Contact Angle
P4 Grade
110mm x 170mm x 28mm
Made in Germany

B7022.E.T.P4S.UL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 25 degrees contact angle and Phenolic cage, bearing is P4 quality and made in Germany

Item: B7022.E.T.P4S.UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel

Quality: P4 Grade

Dimensions: 110mm x 170mm x 28mm /Metric

ID (inner diameter)/Bore: 110mm

OD (outer diameter): 170mm

Width/Height/thickness: 28mm

Size:110 x 170 x 28 mm

Quantity: One Bearing

Dynamic load rating Cr: 106000 N

Static load rating Cor: 73000 N

Limiting Speed:

Grease Lubrication: 7500 RPM

Oil Lubrication: 12,000 RPM

Made in Germany

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

B7022.E.T.P4S.UL FAG original machine tool main spindle bearing,110x170x28mm,B7022.E.T.P4S.UL Spindle bearing
